Specification for Wellhead and Tree Equipment
Specification for Drill Through Equipment
Specification for Casing and Tubing
Specification for Quality Management System Requirements
Specification for Rotary Drill Stem Elements
Specification for Choke and Kill Equipment
We offer a full range of wellhead systems that comply with the latest API 6A guidelines for variable hydrocarbon environments and pressure challenges you can have in your exploration activities. We also have expertise in providing necessary wellhead components for the conversion of wells from standard flow to artificial lift systems.
For information purposes only:
| Minimum product specification level (PSL) for working pressure: | ||||||
| Material Class | 13.8 MPa
(2000 PSI) |
20.7 MPa
(3000 PSI) |
34.5 MPa
(5000 PSI) |
69.0 MPa
(10,000 PSI) |
103.5 MPa
(15,000 PSI) |
138.0 MPa
(20,000 PSI) |
| AA, BB, CC | PSL 1 | PSL 1 | PSL 1 | PSL 2 | PSL 2 | PSL 3 |
| DD, EE, FF | PSL 1 | PSL 1 | PSL 1 | PSL 2 | PSL 3 | PSL 3 |
| HH, ZZ | PSL 3 | PSL 3 | PSL 3 | PSL 3 | PSL 3 | PSL 4 |
Information on API 6A standard stud length and ring gasket
| SIZE | PSI | GASKET
SIZE |
QTY. | STUD DIA | THREAD | FULL THREAD
STUD LENGTH |
TAP END STUD | ||
| TAP END
LENGTH |
NUT END
LENGTH |
TOTAL
LENGTH |
|||||||
| 1-13/16″ | 10K | BX-151 | 8 | 3/4 | 10 UNC | 5.500” | 0.900″ | 1.875″ | 3.750″ |
| 1-13/16″ | 15K | BX-151 | 8 | 7/8 | 9 UNC | 6.000″ | 1.042″ | 2.188″ | 4.125″ |
| 1-13/16″ | 20K | BX-151 | 8 | 1 | 8 UNC | 7.750″ | 1.188″ | 2.500″ | 5.125″ |
| 2- 1/16″ | 2K | RX-23 | 8 | 5/8 | 11 UNC | 5.000″ | 0.761″ | 1.563″ | 3.625″ |
| 2- 1/16″ | 3K | RX-24 | 8 | 7/8 | 9 UNC | 6.500″ | 1.042″ | 2.188″ | 4.625″ |
| 2- 1/16″ | 5K | RX-24 | 8 | 7/8 | 9 UNC | 6.500″ | 1.042″ | 2.188″ | 4.625″ |
| 2- 1/16″ | 10K | BX-152 | 8 | 3/4 | 10 UNC | 5.500″ | 0.900″ | 1.875″ | 3.875″ |
| 2- 1/16″ | 15K | BX-152 | 8 | 7/8 | 9 UNC | 6.500″ | 1.042″ | 2.188″ | 4.375″ |
| 2- 1/16″ | 20K | BX-152 | 8 | 1 1/8 | 8 UN | 8.500″ | 1.313″ | 2.813″ | 5.750″ |
| 2- 9/16″ | 2K | RX-26 | 8 | 3/4 | 10 UNC | 5.500″ | 0.900″ | 1.875″ | 4.000″ |
| 2- 9/16″ | 3K | RX-27 | 8 | 1 | 8 UNC | 7.000″ | 1.188″ | 2.500″ | 5.125″ |
| 2- 9/16″ | 5K | RX-27 | 8 | 1 | 8 UNC | 7.000″ | 1.188″ | 2.500″ | 5.125″ |
| 2- 9/16″ | 10K | BX-153 | 8 | 7/8 | 9 UNC | 6.500″ | 1.042″ | 2.188″ | 4.375″ |
| 2- 9/16″ | 15K | BX-153 | 8 | 1 | 8 UN | 7.250″ | 1.188″ | 2.500″ | 4.875″ |
| 2- 9/16″ | 20K | BX-153 | 8 | 1 1/4 | 8 UN | 9.500″ | 1.438″ | 3.125″ | 6.250″ |
| 3- 1/8″ | 2K | RX-31 | 8 | 3/4 | 10 UNC | 5.750″ | 0.900″ | 1.875″ | 4.125″ |
| 3- 1/8″ | 3K | RX-31 | 8 | 7/8 | 9 UNC | 6.500″ | 1.042″ | 2.188″ | 4.625″ |
| 3- 1/8″ | 5K | RX-35 | 8 | 1 1/8 | 8 UN | 7.750″ | 1.313″ | 2.813″ | 5.625″ |
| 3- 1/16″ | 10K | BX-154 | 8 | 1 | 8 UNC | 7.250″ | 1.188″ | 2.500″ | 5.000″ |
| 3- 1/16″ | 15K | BX-154 | 8 | 1 1/8 | 8 UN | 8.000″ | 1.313″ | 2.813″ | 5.500″ |
| 3- 1/16″ | 20K | BX-154 | 8 | 1 3/8 | 8 UN | 10.250″ | 1.563″ | 3.438″ | 6.750″ |
| 4- 1/16″ | 2K | RX-37 | 8 | 7/8 | 9 UNC | 6.500″ | 1.042″ | 2.188″ | 4.625″ |
| 4- 1/16″ | 3K | RX-37 | 8 | 1 1/8 | 8 UN | 7.500″ | 1.313″ | 2.813″ | 5.500″ |
| 4- 1/16″ | 5K | RX-39 | 8 | 1 1/4 | 8 UN | 8.500″ | 1.438″ | 3.125″ | 6.125″ |
| 4- 1/16″ | 10K | BX-155 | 8 | 1 1/8 | 8 UN | 8.500″ | 1.313″ | 2.813″ | 5.750″ |
| 4- 1/16″ | 15K | BX-155 | 8 | 1 3/8 | 8 UN | 9.750″ | 1.563″ | 3.438″ | 6.500″ |
| 4- 1/16″ | 20K | BX-155 | 8 | 1 3/4 | 8 UN | 12.500″ | 1.938″ | 4.375″ | 8.375″ |
| 5- 1/8″ | 2K | RX-41 | 8 | 1 | 8 UNC | 7.250″ | 1.188″ | 2.500″ | 5.250″ |
| 5- 1/8″ | 3K | RX-41 | 8 | 1 1/4 | 8 UN | 8.250″ | 1.438″ | 3.125″ | 6.000″ |
| 5- 1/8″ | 5K | RX-44 | 8 | 1 1/2 | 8 UN | 10.500″ | 1.688″ | 3.750″ | 7.375″ |
| 5- 1/8″ | 10K | BX-169 | 12 | 1 1/8 | 8 UN | 9.250″ | 1.313″ | 2.813″ | 6.000″ |
| 5- 1/8″ | 15K | BX-169 | 12 | 1-1/2 | 8 UN | 11.500″ | 1.688″ | 3.750″ | 7.625″ |
| 7- 1/16″ | 2K | RX-45 | 12 | 1 | 8 UNC | 7.500″ | 1.188″ | 2.500″ | 5.375″ |
| 7- 1/16″ | 3K | RX-45 | 12 | 1 1/8 | 8 UN | 8.500″ | 1.313″ | 2.813″ | 5.875″ |
| 7- 1/16″ | 5K | RX-46 | 12 | 1 3/8 | 8 UN | 11.250″ | 1.563″ | 3.438″ | 7.500″ |
| 7- 1/16″ | 10K | BX-156 | 12 | 1 1/2 | 8 UN | 11.750″ | 1.688″ | 3.750″ | 7.750″ |
| 7- 1/16″ | 15K | BX-156 | 16 | 1 1/2 | 8 UN | 13.000″ | 1.688″ | 3.750″ | 8.375″ |
| 7- 1/16″ | 20K | BX-156 | 16 | 2 | 8 UN | 17.750″ | 2.188″ | 5.000″ | 11.125″ |
| 9″ | 2K | RX-49 | 12 | 1 1/8 | 8 UN | 8.500″ | 1.313″ | 2.813″ | 5.875″ |
| 9″ | 3K | RX-49 | 12 | 1 3/8 | 8 UN | 9.500″ | 1.563″ | 3.438″ | 6.750″ |
| 9″ | 5K | RX-50 | 12 | 1 5/8 | 8 UN | 12.500″ | 1.813″ | 4.063″ | 8.500″ |
| 9″ | 10K | BX-157 | 16 | 1 1/2 | 8 UN | 13.500″ | 1.688″ | 3.750″ | 8.500″ |
| 9″ | 15K | BX-157 | 16 | 1 7/8 | 8 UN | 16.000″ | 2.063″ | 4.688″ | 10.125″ |
| 9″ | 20K | BX-157 | 16 | 2 1/2 | 8 UN | 21.750″ | 2.688″ | 6.250″ | 13.750″ |
| 11″ | 2K | RX-53 | 16 | 1 1/4 | 8 UN | 9.250″ | 1.438″ | 3.125″ | 6.500″ |
| 11″ | 3K | RX-53 | 16 | 1 3/8 | 8 UN | 10.000″ | 1.563″ | 3.438″ | 7.000″ |
| 11″ | 5K | RX-54 | 12 | 1 7/8 | 8 UN | 14.250″ | 2.063″ | 4.688″ | 9.625″ |
| 11″ | 10K | BX-158 | 16 | 1 3/4 | 8 UN | 15.250″ | 1.938″ | 4.375″ | 9.750″ |
| 11″ | 15K | BX-158 | 20 | 2 | 8 UN | 19.500″ | 2.188″ | 5.000″ | 12.000″ |
| 11″ | 20K | BX-158 | 16 | 2 3/4 | 8 UN | 23.750″ | 2.938″ | 6.875″ | 15.000″ |
| 13- 5/8″ | 2K | RX-57 | 20 | 1 1/4 | 8 UN | 9.500″ | 1.438″ | 3.125″ | 6.625″ |
| 13- 5/8″ | 3K | RX-57 | 20 | 1 3/8 | 8 UN | 10.750″ | 1.563″ | 3.438″ | 7.375″ |
| 13- 5/8″ | 5K | BX-160 | 16 | 1 5/8 | 8 UN | 12.750″ | 1.813″ | 4.063″ | 8.375″ |
| 13- 5/8″ | 10K | BX-159 | 20 | 1 7/8 | 8 UN | 17.750″ | 2.063″ | 4.688″ | 11.000″ |
| 13- 5/8″ | 15K | BX-159 | 20 | 2 1/4 | 8 UN | 21.250″ | 2.438″ | 5.625″ | 13.250″ |
| 13- 5/8″ | 20K | BX-159 | 20 | 3 | 8 UN | 29.750″ | 3.188″ | 7.500″ | 18.125″ |
| 16- 3/4″ | 2K | RX-65 | 20 | 1 1/2 | 8 UN | 10.750″ | 1.688″ | 3.750″ | 7.500″ |
| 16- 3/4″ | 3K | RX-66 | 20 | 1 5/8 | 8 UN | 12.250″ | 1.813″ | 4.063″ | 8.375″ |
| 16- 3/4″ | 5K | BX-162 | 16 | 1 7/8 | 8 UN | 14.750″ | 2.063″ | 4.688″ | 9.500″ |
| 16- 3/4″ | 10K | BX-162 | 24 | 1 7/8 | 8 UN | 17.750″ | 2.063″ | 4.688″ | 11.000″ |
| 18- 3/4″ | 5K | BX-163 | 20 | 2 | 8 UN | 17.750′ | 2.188″ | 5.000″ | 11.250″ |
| 18- 3/4″ | 10K | BX-164 | 24 | 2 1/4 | 8 UN | 22.750″ | 2.438″ | 5.625″ | 14.000″ |
| 18- 3/4″ | 15K | BX-164 | 20 | 3 | 8 UN | 26.750″ | 3.188″ | 7.500″ | 16.750″ |
| 21- 1/4″ | 2K | RX-73 | 24 | 1 5/8 | 8 UN | 12.250″ | 1.813″ | 4.063″ | 8.375″ |
| 20-3/4″ | 3K | RX-74 | 20 | 2 | 8 UN | 15.000″ | 2.188″ | 5.000″ | 10.125″ |
| 21- 1/4″ | 5K | BX-165 | 24 | 2 | 8 UN | 19.000″ | 2.188″ | 5.000″ | 11.750″ |
| 21- 1/4″ | 10K | BX-166 | 24 | 2 1/2 | 8 UN | 24.750″ | 2.688” | 6.250″ | 15.125″ |
| 26- 3/4″ | 2K | BX-167 | 20 | 1 3/4 | 8 UN | 14.250″ | 1.938″ | 4.375″ | 9.125″ |
| 26- 3/4″ | 3K | BX-168 | 24 | 2 | 8 UN | 17.500″ | 2.188″ | 5.000″ | 11.000″ |
| 29-1/2″ | 500 | R-95 | 28 | 1 3/4 | 8 UN | 12.500″ | 1.938″ | 4.375″ | 8.250″ |
| 30″ | 2K | BX-303 | 32 | 1 5/8 | 8 UN | 14.500″ | 1.813″ | 4.063″ | 9.250″ |
| 30″ | 3K | BX-303 | 32 | 1 7/8 | 8 UN | 17.750″ | 2.063″ | 4.688″ | 11.000″ |
For information purposes only:
API 16A Pressure Ratings:
| MPa | 6.9 | 13.8 | 20.7 | 34.5 | 69.0 | 103.4 | 138.0 | 172.7 | 206.8 |
| PSI | 1,000 | 2,000 | 3,000 | 5,000 | 10,000 | 15,000 | 20,000 | 25,000 | 30,000 |
API 16A Temperature Ratings:
| STANDARD TEMPERATURE RANGE | ||
| T-75/250 | - 59°C to 121°C | - 75°F to 250°F |
| T-20/250 | - 29°C to 121°C | - 20°F to 250°F |
| T-0/250 | - 29°C to 121°C | 0°F to 250°F |
| ELEVATED TEMPERATURE RANGE | ||
| T-75/350 | - 59°C to 177°C | - 75°F to 350°F |
| T-20/350 | - 29°C to 177°C | - 20°F to 350°F |
| T-0/350 | - 18°C to 177°C | 0°F to 350°F |
API 16A Bolting Requirements:
| API 20E | Material | Land | Offshore |
| Pressure-controlling bolting | Alloy steel and carbon steel | API 20E BSL-1 | API 20E BSL-2 |
| Closure bolting | API 20E BSL-1 | API 20E BSL-3 | |
| Pressure-retaining bolting | API 20E BSL-2 | API 20E BSL-3 | |
| Utility bolting | Mfg. Spec. | Mfg. Spec. | |
| API 20F | Material | Land | Offshore |
| Pressure-controlling bolting | Stainless steel and CRA | API 20F BSL-2 | API 20F BSL-2 |
| Closure bolting | API 20F BSL-2 | API 20F BSL-3 | |
| Pressure-retaining bolting | API 20F BSL-2 | API 20F BSL-3 | |
| Utility bolting | Mfg. Spec. | Mfg. Spec. |
Pressure-controlling bolting:
Bolting used to assemble or join pressure-controlling parts.
Example: Bolting on ram, seat, or seal retainer bolting, shear ram blade bolting.
Closure bolting:
Bolting used to assemble or join wellbore pressure-containing parts, including end and outlet connections.
Example: Flange bolting, bonnet bolting and end-connection bolting on BOPs, ram door bolting, and hub clamp bolting.
Pressure-retaining bolting:
Bolting used to assemble or join pressure-retaining parts whose failure would result in a release of wellbore fluid to the environment.
Example: Studs and nuts on top of a hydraulic connector, and clamp bolts.
Utility bolting:
All bolting that is required to mount equipment and accessories to the drill through equipment that is not closure bolting, pressure retaining, or pressure controlling.
Example: bolting on lifting eyes, pad eyes (non-welded), wear bushing, nameplate, clamps for tubing, guards.
For information purposes only:
API SPEC Q1, 9th Edition, June 2013 – Specification for Quality Management System Requirements for Manufacturing Organisations for the Petroleum and Natural Gas Industry.
This specification establishes the minimum quality management system requirements for organisations that manufacture products or provide manufacturing-related processes under a product specification for use in the petroleum and natural gas industry.
This specification outlines the requirements of a quality management system for an organisation to demonstrate its ability to consistently provide reliable products and manufacturing-related processes that meet customer and legal requirements.
If an organisation performs activities addressed by this specification, no claims to exclusion of those activities are permitted. Where any requirement of this specification cannot be applied due to the nature of an organisation, the requirement can be considered for exclusion. Where exclusions are made, the basis for claiming exclusions is to be identified. Furthermore, such exclusions cannot affect the organisation’s ability, or responsibility, to provide products and related servicing that meet customer and applicable regulatory requirements.
The quality management system requirements detailed in this specification are in alignment with the section requirements and format of document used for the provision of services and use of service-related product (API Q2). Information marked “NOTE” are not requirements but are provided for guidance in understanding or clarifying the associated requirement.
This standard specifies requirements for the following drill stem elements: upper and lower kelly valves; square and hexagonal kellys; drill stem subs; standard steel and non-magnetic drill collars; drilling and coring bits.
This standard is not applicable to drill pipe and tool joints, rotary shouldered connection designs, thread gauging practice, or grand master, reference master and working gauges.
This specification identifies requirements for the performance, design, materials, testing, inspection, welding, marking, handling, storing, shipment, and purchasing of surface and subsea choke and kill equipment for use in the petroleum and natural gas industries.
These requirements provide for safe and functionally interchangeable surface and subsea choke and kill system equipment. This specification does not apply to field use or field testing. This specification also does not apply to repair of choke and kill equipment, except for weld repair in conjunction with manufacturing.
